Analysis of Free Vibrations in Homogeneous Isotropic Rigidly Fixed Thermoelastic Circumferential Spherical Curved Plates
DOI:
https://doi.org/10.48048/tis.2022.3734Keywords:
Dissipation factor, Lowest frequency, Matrix Fröbenius method, Time harmonics, VibrationsAbstract
The 1st and 2nd class vibrations of rigidly fixed thermoelastic spherical curved plates have been presented in this article. After mathematical modeling, the obtained equations have been solved by applying normal mode analysis. The uncoupled equation has been considered as 1st class vibrations named toroidal vibrations, remains independent of temperature variations. The coupled system of equations which is considered as 2nd class vibrations named spheroidal vibrations. The series solution of matrix Fröbenius method has been applied to coupled system of ordinary differential equations to obtain potentials and temperature. Fixed point iteration numerical technique has been applied to analytical results with the assistance of MATLAB software tools. Computational techniques have been applied to analytical results and numerically generated data has been represented graphically for frequencies, dissipation factor, displacements and temperature.
HIGHLIGHTS
- The 1st and 2nd class vibrations of rigidly fixed thermoelastic spherical curved plates have been presented in this article
- The uncoupled equation has been considered as 1st class vibrations named toroidal vibrations, remains independent of temperature variations
- The coupled system of equations which is considered as 2nd class vibrations named spheroidal vibrations
- The series solution of matrix Fröbenius method has been applied to couple system of ordinary differential equations to obtain potentials and temperature
- Computational techniques have been applied to analytical results and numerically generated data has been represented graphically for frequencies, dissipation factor, displacements and temperature
GRAPHICAL ABSTRACT
Downloads
Metrics
References
H Cohen, AH Shah and CV Ramakrishan. Free vibrations of a spherically isotropic hollow sphere. Acustica 1972; 26, 329-33.
HJ Ding, WQ Chen and Z Liu. Solutions to equations of vibrations of spherical and cylindrical shells. Appl. Math. Mech. 1995; 16, 1-15.
S Towfighi, T Kundu and M Ehsani. Elastic wave propagation in circumferential direction in anisotropic cylindrical curved plates. J. Appl. Mech 2002; 69, 283-91.
S Towfighi and T Kundu. Elastic wave propagation in anisotropic spherical curved plates. Int. J. Solids Struct. 2003; 40, 5495-510.
J Yu and Q Ma. Wave characteristics in magneto-electro-elastic functionally graded spherical curved plates. Mech. Adv. Mater. Struct. 2010; 17, 287-301.
JN Sharma and N Sharma. Three-dimensional free vibration analysis of a homogeneous transradially isotropic thermo-elastics sphere. J. Appl. Mech 2010; 77, 021004-1-9.
JN Sharma, DK Sharma and SS Dhaliwal. Three-dimensional free vibration analysis of a viscothermoelastic hollow sphere. Open J. Acoust. 2012; 2, 12-24.
JN Sharma, DK Sharma and SS Dhaliwal. Free vibration analysis of a rigidly fixed viscothermoelastic hollow sphere. Ind. J. Pure Appl. Math. 2013; 44, 559-86.
JG Yu, JE Lefebvre and L Elmaimouni. Toroidal wave in multilayered spherical curved plates. J. Sound Vib. 2013; 332, 2816-30.
IA Abbas. Analytical solution for a free vibration of a thermoelastic hollow sphere. Mech. Based Des. Struc. 2015; 43, 265-76
JJ Tripathi, GD Kedar and KC Deshmukh. Generalized thermoelastic diffusion problem in a thick circular plate with axisymmetric heat supply. Acta Mech. 2015; 226, 2121-34.
N Sharma. Circumferential waves in transradially isotropic thermoelastic spherical curved plates. Proc. Natl. Acad. Sci. India Section A 2017; 87, 57-72.
DK Sharma, M Bachher and N Sarkar. Effect of phase-lags on the transient waves in an axisymmetric functionally graded viscothermoelastic spherical cavity in radial direction. Int. J. Dyn. Control. 2021; 9, 424-37.
K Singh and R Muwal. Thermoelastic strain and stress fields due to a spherical inclusion in an elastic half space. J. Theor. Appl. Mech. 2017; 55, 1369-80.
DK Sharma, MK Sharma and N Sarkar. Effect of three-phase-lag model on the analysis of three-dimensional free vibrations of viscothermoelastic solid cylinder. Appl. Math. Model 2021; 90, 281-301.
SR Sharma, JC Mehalwal, N Sarkar and DK Sharma. Vibration analysis of electro-magneto transversely isotropic non-local thermoelastic cylinder with voids material. Eur. J. Mech. A Solids 2022; 92, 104455.
SR Sharma, JC Mehalwal, N Sarkar and DK Sharma. Nonlocal elasticity and thermal dual-phase-lag effect on the vibration analysis of transversely isotropic electro-magneto generalized thermoelastic sphere with voids. Z. fur Angew. Math. Mech. 2022; 102, e202100200.
HW Lord and Y Shulman. A generalization of dynamical theory of thermoelasticity. J. Mech. Phys. Solids 1967; 15, 299-309.
AE Green and KA Lindsay, Thermo-elasticity. J. Elast. 1972; 2, 1-7.
H Ding, W Chen and L Zhang. Elasticity of transversally isotropic materials. Springer, Dordrecht, The Netherlands, 2006.
DS Chanderasekharaiah. Thermoelasticity with second sound: A review. Appl. Mech. Rev. 1986; 39, 355-76.
