Study of the Optical, Structural and Morphological Properties of Electrodeposited Copper Manganese Sulfide (CuMnS) Thin Films for Possible Device Applications
DOI:
https://doi.org/10.48048/tis.2022.5747Keywords:
Thin films, Electrodeposition, Bandgap, X-ray diffraction, Morphology, Photovoltaic CellAbstract
Semiconductor thin films of CuMnS have been deposited onto conductive fluorine-doped tin oxide (FTO) glass substrate using an electrodeposition method to investigate their properties for possible applications. Copper sulfate, manganese sulfate and Thiourea were precursors used for sources of copper, manganese and sulphur ions respectively. The concentration of manganese ions was varied while keeping deposition voltage and time constant at 0.6 and 100 s, respectively. The films were characterized for optical, structural and morphological properties. The results obtained showed that the absorbance of the films is high in the visible (VIS) and near-infrared (NIR) regions but decreases towards NIR. The films transmittance is low in the VIS but increased in the NIR regions. The extinction coefficient is low in the VIS and NIR regions and decreases as concentration of manganese ion increased. The refractive index is high and initially increased slightly from 4.49 to 4.68 in the mid-VIS region while manganese concentration increased from 0.05 to 0.15 M and then decreased to the value of 2.73 as concentration of manganese ion increased further. The optical conductivity is high throughout the VIS and NIR regions while the optical bandgap energy is in the range of 1.5 to 2.05 eV and increases as manganese ion concentration increased. The XRD analysis showed that the deposited thin films of CuMnS are crystalline with average crystallite size and micro-strain in the range of 15.86 - 24. 45 nm and 3.97×10–3 - 6.13×10–3, respectively. The SEM results showed that the films are composed of particle sizes that are spherical in shape, uniform in sizes and densely packed together and consequently make the film surface rough. These properties exhibited by the films make them good materials for applications in photovoltaic calls, solar control coatings, photothermal applications and many other electronic devices that require high temperatures.
HIGHLIGHTS
- This paper focused on the study of the effect of manganese ion concentration on the chalcogenide semiconductor thin films of CuMnS for possible device applications
- Electrodeposition method was used to fabricate the semiconductor thin films of CuMnS
- Optical, Structural and morphological properties of the thin films were characterized
- The deposited thin films of CuMnS were found to have good applications for photovoltaic cells and other optoelectronic device fabrications
GRAPHICAL ABSTRACT
Downloads
References
MC Ohakwere-Eze. The growth and characterization of copper sulphide thin films using CBD (chemical bath deposition) technique. J. Mater. Sci. Eng. B. 2015; 5, 181-6.
MS Shinde, PB Abirao, IJ Patil and RS Patil. Thickness dependent electrical and optical properties of nanocrystalline copper sulphide thin films grown by simple chemical route. Indian J. Pure Appl. Phys. 2012; 50, 657-60.
YE Firat, H Yildirim, K Erturk and A Peksov. Ultrasonic spray pyrolysis deposited copper sulphide thin films for solar cell applications. Hindawi Scanning 2017; 2017, 2625132.
HM Pathan and CD Lokhande. Deposition of metal chalcogenide thin films by succesive ionic layer adsorption and reaction (SILAR) method. Bulletin Mater. Sci. 2004; 27, 85-111.
ADA Buba and JSA Adelabu. Electrical conductivity of Cu¬¬xS thin film deposited by chemical bath deposition (CBD) technique. Nigerian J. Basic Appl. Sci. 2009; 17, 161-5.
NP Huse, DS Upadhyea, AS Dive and R Sharma. Study of opto-electronic properties of copper sulphide thin film grown by chemical bath deposition technique for electronic device application. Invertis J. Renew. Energy. 2016; 6, 74-8.
E Güneri and A Kariper. Optical properties of amorphous CuS thin films deposited chemically at different pH values. J. Alloys Compd. 2012; 516, 20-6.
PC Okafor and AJ Ekpunobi. The effect of manganese percentage doping on the thickness and conductivity of copper sulphide nano films prepared by electrodeposition method. Int. J. Sci Eng. Res. 2016; 7, 174-7.
S Jahan, MNH Liton, MKR Khan and MM Rahman. Effect of aluminum doping on the properties of spray deposited copper sulphide (Cu2S) thin films. Int. J. Adv. Eng. Technol. 2015; VI, 23-7.
P Priyadharshini and R Revathy. Synthesis and characterization of metal doped nano crystallinn copper sulphide. Int. J. Recent Sci. Res. 2015; 6, 3328-31.
PC Okafor and AJ Ekpunobi. Effect of manganese doping percentage on band gap energy of cadmium sulphide (CdS) nano-films prepared by electrodeposition method. Int. J. Sci. Res. 2015; 4, 2280-4.
N Arbi, IB Assaker, M Gannouni, A Krisa and R Chtourou, Effect of manganese concentration on physical and electrochemical properties of Mn2+ doped ZnS thin films deposited onto ITO (glass) substrates by electrodeposition technique. J. Mater. Sci.: Mater. Electron. 2017; 28, 4997-5005.
MZ Igbal, S Zakar, SS Haider, AM Afzal, MJ Igbal, MA Kamran and A Numan. Electrodeposited CuMnS and CoMnS electrodes for high-performance asymmetric supercapacitor devices. Ceram. Int. 2020; 46, 21343-50.
H Liu, Z Guo, X Wang, J Hao and J Lian. CuS/MnS composite hexagonal nanosheet clusters: Synthesis and enhanced pseudocapacitive properties. Electochim. Acta. 2018; 271, 425-32.
JCC Akunna, LN Ezenwaka, IE Otti and NS Umeokwonna. The effects of concentration on the optical properties of manganese alloyed copper (ii) sulphide thin films deposited by chemical bath deposition technique. COOU J. Phys. Sci. 2020; 3, 362-71.
KA Mohammed, SM Ahmed and RY Mohammed. Investigation of structure, optical, and electrical properties of CuS thin films by CBD technique. Crystals 2020; 10, 684.
SM Salem, NM Deraz and HA Saleh. Fabrication and characterization of chemically deposited copper manganese sulfide thin films. Appl. Phys. A: Mater. Sci. Process. 2020; 126, 700.
IL Ikhioya, PN Okanigbuan, CB Agbakwuru and BU Osolobri. Characterization of zinc sulphide/cadmium sulphide (ZnS/CdS) superlattice by electrodeposition technique. J. Nigerian Assoc. Math. Phys. 2015; 29, 331-8.
IL Ikhioya, S Ehika amd NN Omehe. Electrochemical deposition of lead sulphide (PbS) thin films deposition on zinc plate substrate. J. Mater. Sci. Res. Rev. 2018; 1, 1-11.
IA Karipers. Optical and structural proprties of Bi/Ag-I thin films by co-precipitation method. Asian J. Chem. 2016; 28, 2241-5.
AA Kadhim, RA Alansary and SA Alhady. Effect of Mn concentration on the structural and optical properties of SnO2 thin films prepared by pulse laser deposition. J. Res. Method Educ. 2014; 4, 12-9.
İA Kariper, Ş Özden and FM Tezel. Optical properties of selenium sulfide thin films produced via chemical dropping method. Opt. Quantum Electron. 2018; 50, 144.
A Ohwofosirai, MD Femi, NA Ngozika, TO Joseph, RU Osuji and BA Ezekoye. A study of the optical conductivity, extinction coefficient and dielectric function of CdO by sucessive ionic layer adsorption and reaction (SILAR) technique. Chem. Sci. Int. J. 201; 4, 736-44.
MA Sangamesha, K Pushpalatha, GL Shekar and S Shamsundar. Preparation and characterization of nanocrystalline CuS thin films for dye-sensitized solar cells. Int. Scholarly Res. Notices. 2013; 2013, 829430.
A Ekpekpo and IR Ufuoma. Characterization of copper sulfide (CuS) hin films syntheized by electroless plating. Int. Res. J. Pure Appl. Phys. 2019; 6, 20-35.
İA Kariper and F Göde. Influence of pH on the structural and optical properties of polycrystalline MnTe2 thin films produced by chemical bath deposition method. Acta Phys. Pol. A. 2017; 132, 531-4.
A Hannachi, S Hammami, N Raouafi and H Maghraoui-Meherzi. Preparation of manganese sulfide (MnS) thin films by chemical bath deposition: Application of the experimental design methodology. J. Alloys Compd. 2016; 663, 507-15.
M Karunakaran, S Maheswari, K Kasirajan, SD Raj and R Chandramohan. Structural and optical properties of Mn-doped ZnO thin films prepared by SILAR Method. Int. Lett. Chem. Phys. Astron. 2017; 73, 22-30.
M Karunakaran, S Maheswari, K Kasirajan, SD Raj and R Chandramohan. Structural and optical properties of Mn-Doped ZnO thin films prepared by SILAR method. Int. Lett. Chem. Phys. Astronomy. 2017; 73, 22-30.
AI Hassan and SI Maki. Structural and optical properties of copper-doped cobalt oxide thin films prepared by spray pyrilysis. Int. J. Eng. Res. Technol. 2017; 6, 535.
K Girija, S Thirumalairajan, SM Mohan and J Chandrasekaran. Structural, morphological and optical studies of CdSe thin films from ammonia bath. Chalcogenide lett. 2009; 6, 351-7.
P Prasoon, P Jayaram, NK Sulfikkarali and NK Deepak. Micro-strain, dislocation density, surface morphology and optoelectronic properties of indium zinc oxide thin films. Int. J. Res. Advent Technol. 2018; 6, 3486-91.
