Evaluation of Non-Isothermal Kinetic Parameters for Pyrolysis of Teak Wood using Model-Fitting Techniques

Authors

  • Adekunle Adeleke Mechanical Engineering Department, Landmark University, PMB 1001, Omu-Aran, Nigeria
  • Peter Ikubanni Mechanical Engineering Department, Landmark University, PMB 1001, Omu-Aran, Nigeria
  • Jamiu Odusote Materials and Metallurgical Engineering Department, University of Ilorin, PMB 1515, Ilorin, Nigeria
  • Thomas Orhadahwe Mechanical Engineering Department, University of Ibadan, Ibadan, Nigeria
  • Olumuyiwa Lasode Mechanical Engineering Department, University of Ilorin, PMB 1515, Ilorin, Nigeria
  • Samuel Adegoke Petroleum Engineering Department, University of Ibadan, Ibadan, Nigeria
  • Olanrewaju Adesina Mechanical Engineering Department, Landmark University, PMB 1001, Omu-Aran, Nigeria

DOI:

https://doi.org/10.48048/tis.2021.1432

Keywords:

Model-fitting techniques, Teak wood dust, Thermogravimetry, Frequency factor, Activation energy

Abstract

Teak wood is one of the prominently used raw material in the construction industry, thus contributing extremely to the biomass waste available in Nigeria. These wastes are usually used for energy generation that requires upgrade into better fuel before application. Hence, the present study evaluates the non-isothermal kinetic parameters for pyrolysis of teak wood using model-fitting techniques. Teak wood dust was subjected to proximate, ultimate and calorific value analyses based on different ASTM standards. The thermal degradation and decomposition behaviour of the teak wood dust was examined using a thermogravimetric analyzer. Pulverized teak (6.5 mg) was heated from 30 to 800 ºC at varying heating rates (5, 10 and 15 ºC) in an environment where 100 mL/min of nitrogen gas was charged in continuously to maintain an inert condition. Avrami-Erofeev, Ginstling-Broushtein (GB) and Mampel models were used to evaluate the kinetic parameters of the pyrolysis of teak wood dust. The teak wood dust contained 7.25 % moisture, 79.26 % volatile matter (VM), 1.74 % ash and 11.75 % fixed carbon. The calorific value of the wood dust was 18.72 MJ/kg. The results of the thermogravimetric analyses depicted that heating rate has no effect on weight loss during the reactive drying zone. However, as the thermal treatment progressed into the active pyrolysis and passive pyrolysis zones, the weight loss decreased with increase in heating rate.  The devolatilization parameters also increased with heating rates except for the maximum conversion. The results of the kinetic parameters evaluation revealed that the GB model was best fit to evaluate the kinetic parameters of teak in the active pyrolysis zone while GB and Mampel models were considered most appropriate for the evaluation of the kinetic parameters in the passive pyrolysis zone. Model-fitting method has the capacity to capture a wide range of fractional conversion at a glance.

HIGHLIGHTS

  • Arrhenius parameters in terms of activation energy and pre-exponential factor for the pyrolysis of teak wood while comparing 4 different model-fitting techniques were obtained
  • The α-temperature plot for solid state reaction of teak wood dust was a bell-shape (sigmoidal model)
  • The Avrami-Erofeev and SSS models were unable to capture the overlapping multiple reactions that took place simultaneously at the active pyrolysis zone
  • Higher energy input is needed for devolatilization of teak wood dust to give 10 - 80 % conversion due to higher activation energy at the active pyrolysis zone
  • Ginstling-Broushtein was found to be the best model for evaluating the kinetic parameters at the active pyrolysis zone as it had the highest R2 value


GRAPHICAL ABSTRACT

Downloads

Download data is not yet available.

References

JK Odusote, AA Adeleke, OA Lasode, M Malathi and D Paswan. Thermal and compositional properties of treated Tectona grandis. Biomass Convers. Biorefinery 2019; 9, 511-9.

E Okoroigwe. Combustion analysis and devolatilazation kinetics of gmelina, mango, neem and tropical almond woods under oxidative condition. Int. J. Renew. Energy Res. 2015; 5, 1024-33.

AA Adeleke, PP Ikubanni, JK Odusote, TA Orhadahwe, OA Lasode, SO Adegoke and OS Adesina. Non-isothermal kinetic parametric evaluation of Tectona grandis using model-fitting methods. Mater. Today Proc. 2021; 44, 2874 -8.

AA Adeleke, JK Odusote, PP Ikubanni, OA Lasode, M Malathi and D Paswan. Essential basics on biomass torrefaction, densification and utilization. Int. J. Energy Res. 2021; 45, 1375-95.

OA Lasode, AO Balogun and AG McDonald. Torrefaction of some nigerian lignocellulosic resources and decomposition kinetics. J. Anal. Appl. Pyrolysis 2014; 109, 47-55.

W Jin, K Singh and J Zondlo. Pyrolysis kinetics of physical components of wood and wood-polymers using isoconversion method. Agriculture 2013; 3, 12-32.

JL Goldfarb and C Liu. Impact of blend ratio on the co-firing of a commercial torrefied biomass and coal via analysis of oxidation kinetics. Bioresour. Technol. 2013; 149, 208-15.

AA Adeleke, JK Odusote, OA Lasode, PP Ikubanni, M Malathi and D Paswan. Mild pyrolytic treatment of Gmelina arborea for optimum energetic yields. Cogent Eng. 2019; 6, 1593073.

A Dhaundiyal and SB Singh. Asymptotic approximations to the non-isothermal distributed activation energy model for biomass pyrolysis. Acta Mech. Autom. 2017; 11, 293-301.

A Soria-verdugo, TM Morgano, H Matzing, E Goos, H Leibold, D Merz, U Riedel and D Stapf. Comparison of wood pyrolysis kinetic data derived from thermogravimetric experiments by model- fitting and model-free methods. Energy Convers. Manag. 2020; 212, 112818.

MP Kothandaraman and M Somasundaram. Non-isothermal kinetic study on copyrolysis of Juliflora and low-density polyethylene. Biomass Convers. Biorefinery 2021; 11, 2147-55.

G Varhegyi, L Wang and O Skreiberg. Non‑isothermal kinetics: Best‑fitting empirical models instead of model-free methods. J. Therm. Anal. Calorim. 2019; 142, 1043-54.

D Pradhan, GS Mahobia, K Chattopadhyay and V Singh. Effect of surface roughness on corrosion behavior of the superalloy IN718 in simulated marine environment. J. Alloys Compd. 2018; 740, 250-63.

JLF Alves, JCGD Silva, VFDS Filho, RF Alves, WVDA Galdino and RFD Sena. Kinetics and thermodynamics parameters evaluation of pyrolysis of invasive aquatic macrophytes to determine their bioenergy potentials. Biomass Bioenergy 2019; 121, 28-40.

MY Guida, S Lanaya, Z Rbihi and A Hannioui. Thermal degradation behaviors of sawdust wood waste: Pyrolysis kinetic and mechanism. J. Mater. Environ. Sci. 2019; 10, 742-55.

AA Adeleke, JK Odusote, OA Lasode, PP Ikubanni, M Malathi and D Paswan. Densification of coal fines and mildly torrefied biomass into composite fuel using different organic binders. Heliyon 2019; 5, e02160.

E Barta-Rajnai, G Varhegyi, L Wang, O Skreiberg and M Gronli and Z Czegeny. Thermal decomposition kinetics of wood and bark and their torrefied products. Energy Fuels 2017; 31, 4024-34.

RK Chaturvedi and AS Raghubanshi. Allometric models for accurate estimation of aboveground biomass of teak in tropical dry forests of India. Forest Sci. 2015; 61, 938-49.

AA Adeleke, JK Odusote, OA Lasode, D Paswan and M Malathi. Influence of torrefaction on lignocellulosic woody biomass of Nigerian origin. J. Chem. Technol. Metall. 2019; 54, 274-85.

QV Bach, WH Chen, CF Eng, CW Wang, KC Liang and JY Kuo. Pyrolysis characteristics and non-isothermal torrefaction kinetics of industrial solid wastes. Fuel 2019; 251, 118-25.

EAH Castillejos and MFF Tania. Characterization of roughness, porosity and thermal resistances of continuous casting mold slag layers devitrified and crystallized in laboratory. Metall. Mater. Trans. B 2019; 50, 2436-53.

SM Al-Salem, A Bumajdad, AR Khan, BK Sharma, SR Chandrasekaran, FA Al-Turki, FH Jassem, and AT Al-Dhafeeri. Non-isothermal degradation kinetics of virgin linear low density polyethylene (LLDPE) and biodegradable polymer blends. J. Polym. Res. 2018; 25, 111.

JE White, WJ Catallo and BL Legendre. Biomass pyrolysis kinetics: A comparative critical review with relevant agricultural residue case studies. J. Anal. Appl. Pyrolysis 2011; 91, 1-33.

AW Coats and JP Redfern. Kinetic parameters from thermogravimetric data. Nature 1964; 201, 68-9.

AA Adeleke, JK Odusote, OA Lasode, PP Ikubanni, M Madhurai and D Paswan. Evaluation of thermal decomposition characteristics and kinetic parameters of melina wood. Biofuels 2019, DOI: 10.1080/17597269.2019.1646541.

AO Balogun, OA Lasode and AG McDonald. Thermo-analytical and physico-chemical characterization of woody and non-woody biomass from an agro-ecological zone in Nigeria. Bioresources 2014; 9, 5099-113.

AD Kamble, VK Saxena, PD Chaven and VA Mendhe. Co-gasification of coal and biomass an emerging clean energy technology: Status and prospects of development in Indian context. Int. J. Mining Sci. Technol. 2019; 29, 171-86.

AM Azeez, D Meier, J Odermatt and T Wilner. Fast pyrolysis of African and European linocellulosic biomasses usin Py-GC/MS and fluidized bed reactor. Energy Fuels 2010; 24, 2078-85.

PJ Skrdla and RT Robertson. Semi-empirical equations for modeling solid-state kinetics based on a Maxwell-Boltzmann distribution of activation energies: Applications to a polymorphic transformation under crystallization slurry conditions and to the thermal decomposition of AgMnO4 crystals. J. Phys. Chem. B 2005; 109, 10611-19.

A Khawam and DR Flanagan. Solid-state kinetic models: Basics and mathematical fundamentals. J. Phys. Chem. B 2006; 110, 17315-28.

NA Liu, W Fan, R Dobashi and L Huang. Kinetic modeling of thermal decomposition of natural cellulosic materials in air atmosphere. J. Anal. Appl. Pyrolysis 2002; 63, 303-25.

DA Mortari, I Avila, AMD Santos and PM Crnkovic. Study of thermal decomposition and ignition temperature of bagasse, coal and their blends. Therm. Eng. 2010; 9, 81-8.
