Performance Evaluation of Ternary Blends of Pulverized Cow Bone Ash and Waste Glass Powder on the Strength Properties of Concrete
DOI:
https://doi.org/10.48048/tis.2022.3222Keywords:
Pulverized cow bone ash, Waste glass powder, Ternary blends, Compressive strength, Tensile strengthAbstract
The amounts of agricultural waste in cow bone and industrial waste glass in Nigeria have been expanding significantly, thereby increasing the danger to general wellbeing particularly in urban communities. This research examined the suitability of ternary blends of pulverized cow bone ash and waste glass powder (PCBAWGP) equally combined and partially replaced Portland cement in 0, 10, 20, 30 and 40 % percentages in concrete production. Physical and chemical properties were done on the concrete constituent materials. Compressive and tensile strengths of the hardened concrete of grade M20, mix proportion 1:2.17:3.4 were tested after 7, 14, 28, 60 and 90 days. The result of the physical properties uncovered that PCBAWGP had 2.70, 2.05 % and 1364 kg/m3 for specific gravity, moisture content and bulk density, respectively. From the consequences of the compressive strength, it showed that as the curing age of the concrete increases, the compressive strength expanded, the compressive strength outcomes at 10 % PCBAWGP partially replaced concrete is 15.55, 24.15, 19.85, 27.60 and 37.98 N/mm2 individually at 7, 14, 28, 60 and 90 days. At 90 days curing age, the tensile strength results for the control mix and 20 % PCBAWGP replacement was 2.72 and 1.88 N/mm2, respectively. The concrete strengths improved with concrete age and this was statistically affirmed utilizing ANOVA. This investigation showed that utilizing PCBAWGP in concrete is sustainable thereby reducing the dumped wastes and lessen CO2 outflows into the atmosphere by diminishing the extent of Portland cement in unit volume of cement produced.
HIGHLIGHTS
- The compressive strength of concrete reduces as % pulverized cow bone ash and waste glass powder PCBAWGP increases. The compressive strength generally increases with increase in age of curing. The minimum and maximum compressive strength of concrete at 10 and 40 % PCBAWGP content for 1:2.17:3.4 concrete mix ratio at 28- and 90-days curing age are 19.85, 37.98 N/mm2 and 15.68, 22.31 N/mm2, respectively
- The minimum and maximum tensile strength of concrete at 10 and 40 % PCBAWGP at 28- and 90-days curing age are 1.71, 2.19 N/mm2 and 0.70, 1.55 N/mm, respectively
- The result of the water absorption tests at 28 days and 90 days showed that concrete samples containing PCBAWGP built up a superior protection from harm by freezing as their outcomes were less than 7 % recommendation
- Concrete containing PCBAWGP contents up to 20 % as partial replacement for cement, fulfills the strength required for normal concrete
- From the production comparative cost analysis, concrete with PCBAWGP content, as partial substitution for cement, is cheaper than conventional concrete of equivalent strength
GRAPHICAL ABSTRACT
Downloads
Metrics
References
AA Akindahunsi and HC Uzoegbo. Strength and durability properties of concrete with starch admixture. Int. J. Conc. Struct. Mater. 2015; 9, 323-35.
S Ibrahim and A Meawad. Assessment of waste packaging glass bottles as supplementary cementitious materials. Construct. Build. Mater. 2018; 182, 451-8.
AZ Isiksal and OJ Chimezie. Impact of industrialization in Nigeria. Eur. Sci. J. 2016; 12, 328.
R McCaffery. Climate change and the cement industry. Global Cement and Lime Magazine, London, 2002, p. 15-9.
Z Giergiczny, A Król, M Tałaj and K Wandoch. Performance of concrete with low CO2 emission. Energies 2020; 13, 4328.
S Das, SH Lee, P Kumar, KH Kim, SS Lee and SS Bhattacharya. Solid waste management: Scope and the challenge of sustainability. J Cleaner Prod. 2019; 228, 658-78.
V Gokulnath, B Ramesh and K Priyadharsan. Study on m-sand in self compacting concrete with addition of glass powder in m-25 grade - A review. Mater. Today Proc. 2020; 22, 659-62.
OA Adetayo and CA Opasina. Variation in the strength properties of concrete using waste glass as partial replacement for different coarse aggregate grading. ACTA Technica Corviniensis Bull. Eng. 2019; 12, 11-5.
F Falade, E Ikponmwosa and C Fapohunda. Low cost construction through the use of pulverized bone foamed aerated concrete (FB-FAC). Civ. Environ. Res. 2013; 3, 107-13.
F Falade, E Ikponmwosa and C Fapohunda. Flexural performance of foam concrete containing pulverized bone as partial replacement of cement. Maejo Int. J. Sci. Tech. 2014; 8, 20-31.
OA Adetayo and OA Bucknor. Comparative study on the effect of grinded rice husk and rice husk ash on compressive strength of concrete. ACTA Technica Corviniensis Bull. Eng. 2018; 11, 73-6.
AO Bucknor, FM Animashaun, FA Olutoge, OA Adetayo, WO Ajagbe and EE Ikponmwosa. Investigating the fracture characteristics of Nigerian rice husk ash (RHA) - based high strength concrete (HSC). Int. J. Civ. Struct. Eng. Res. 2020; 8, 122-9.
AO Bucknor, FM Animashaun, FA Olutoge and OA Adetayo. Exploring the suitability of Nigerian-based rice husk ash for high strength concrete production for use in construction. Int. J. Civ. Struct. Eng. Res. 2019; 7, 8-15.
OA Adetayo and OJ Ubril. Effect of ripe and unripe plantain peel ash on concrete workability and compressive strength. Federal Univ. Oye Ekiti J. Eng. Tech. 2019; 4, 145-8.
OA Adetayo, OO Amu and AO Ilori. Cement stabilized structural foundation lateritic soil with bone ash powder as additive. Arid Zone J. Eng. Tech. Environ. 2019; 15, 479-87.
SM Varma, M Naidu, S Mohan and S Reddy. An effective study on utilizing bone powder ash as partial replacement of construction material. Int. J. Innov. Tech. Res. 2016; 4, 3060-2.
P Shafigh, HB Mahmud, Z Jumaat, R Ahmmad and S Bahri. Structural lightweight aggregate concrete using two types of waste from the palm oil industry as aggregate. J. Cleaner Prod. 2014; 80, 187-96.
UJ Alengaram, BAA Muhit and MZB Jumaat. Utilization of oil palm kernel shell as lightweight aggregate in concrete - a review. Construct. Build. Mater. 2013; 1, 161-72.
S Egamana and S Sule. Optimization of compressive strength of periwinkle shell aggregate concrete. Niger. J. Tech. 2017; 36, 32-8.
AA Umoh and KO Olusola. Comprehensive strength and static modulus of elasticity of periwinkle shell ash blended cement concrete. Int. J. Sustain. Construct. Eng. Tech. 2012; 3, 45-55.
OA Adetayo, OO Amu and OS Alabi. Improvement of cement stabilized structural lateritic with pulverized snail shell. SSP J. Civ. Eng. 2019; 14, 95-106.
O Ketebu and ST Farrow. Experimental investigation of snail shell ash (SSA) as partial replacement of ordinary portland cement in concrete. Int. J. Eng. Res. Tech. 2017; 3, 1049-53.
BR Etuk, IF Etuk and LO Asuquo. Feasibility of using sea shells ash as admixtures for concrete. J. Environ. Sci. Eng. A 2012; 1, 121-7.
OE Alutu and TO Ehondor. The setting time of Portland cement pastes dosed with cassava starch admixtures. Niger. J. Ind. Syst. Stud. 2005; 4, 24-31.
SA Ademola and TA Buari. Behaviour of bamboo leaf ash blended cement concrete in sulphate environment. IOSR J. Eng. 2014; 4, 1-8.
AA Umoh and IA Odesola. Characteristics of bamboo leaf ash blended cement paste and mortar. Civ. Eng. Dimen. 2015; 17, 22-8.
M Ramya and SR Mercy. Evaluation of sustainable green concrete with partial replacement of cement by banana leaf powder and cattle bone powder. Indian J. Appl. Res. 2016; 6, 7-10.
O Amu, O Adetayo, F Faluyi and E Akinyele. Experimental study of improving the properties of lime-stabilized structural lateritic soil for highway structural works using groundnut shell ash. Walailak J. Sci. Tech. 2021; 18, 9475.
KA Mujedu and SA Adebara. The use of groundnut shell ash as a partial replacement for cement in concrete production. Int. J. Sci. Eng. Environ. Tech. 2016; 1, 32-9.
JA Bhat, RA Qasab and AR Dar. Machine crushed animal bones as partial replacement of coarse aggregates in lightweight concrete. ARPN J. Eng. Appl. Sci. 2012; 7, 1202-7.
OM Olofinnade, JM Ndambuki, AN Ede and C Booth. Application of waste glass powder as a partial cement substitute towards more sustainable concrete production. Int. J. Eng. Res. Af. 2017; 31, 77-93.
X Zhang, Y Wu and L Shen. Application of low waste technologies for design and construction: A case study in Hong Kong. Renew. Sustain. Energ. Rev. 2012; 16, 2973-9.
J Lapeyre and A Kumar. Influence of pozzolanic additives on hydration mechanisms of tricalcium silicate. J. Am. Ceram. Soc. 2018; 101, 3557-74.
GMS Islam, MH Rahman and N Kazi. Waste glass powder as partial replacement of cement for sustainable concrete practice. Int. J. Sustain. Built Environ. 2017; 6, 37-44.
K Afshinnia and PR Rangaraju. Impact of combined use of ground glass powder and crushed glass aggregate on selected properties of Portland cement concrete. Construct. Build. Mater. 2016; 117, 263-72.
SC Bostanci. Use of waste marble dust and recycled glass for sustainable concrete production. J. Cleaner Prod. 2020; 251, 119785.
HY Wang and WL Huang. A study on the properties of fresh self-consolidating glass concrete. Construct. Build. Mater. 2010; 24, 619-24.
H Dehghanpour and K Yılmaz. Evaluation and investigation of waste glass aggregates and powders in architectural mortars. Russ. J. Build. Construct. Architect. 2019; 44, 28-42.
H Du and KH Tan. Properties of high volume glass powder concrete. Cement Concr. Compos. 2017; 75, 22-9.
DO Omole and AS Ogbiye. An evaluation of slaughterhouse wastes in south-west Nigeria. Am. J. Env. Protect. 2013; 2, 85-9.
OA Adetayo, OM Umego, F Faluyi, AO Odetoye, AO Bucknor, AA Busari and A Sanni. Evaluation of pulverized cow bone ash and waste glass powder on the geotechnical properties of tropical laterite. Silicon 2021, https://doi.org/10.1007/s12633-021-00999-4.
NM Ogarekpe, JC Agunwamba, FO Idagu, ES Bejor, OE Eteng, HE Ndem and EO Oloko. Suitability of burnt and crushed cow bones as partial replacement for fine aggregate in concrete. Niger. J. Tech. 2017; 36, 686-90.
S Morgulis. Studies of the chemical composition of bone ash. J. Biol. Chem. 1931; 93, 455-66.
A Mehta and DK Ashish. Silica fume and waste glass in cement concrete production: A review. J. Build. Eng. 2020; 29, 100888.
Y Liu, C Shi, Z Zhang and N Li. An overview on the reuse of waste glasses in alkali-activated materials. Resour. Conservat. Recycl. 2019; 144, 297-309.
HE Abdelli, L Mokrani, S Kennouche and JLB Aguiar. Utilization of waste glass in the improvement of concrete performance: A mini review. Waste Manag. Res. 2020; 38, 1204-13.
British Standards Institution. Structural use of concrete - part 1: Code of practice for design and construction. British Standards Institution, London, 1997.
OE Oluwatuyi, EC Ashaka and OO Ojuri. Cement stabilization treatment of lead and naphthalene contaminated lateritic soils. J. Environ. Eng. Landsc. Manag. 2019; 27, 41-8.
D Dahiru, US Yusuf and NJ Paul. Characteristics of concrete produced with periwinkle and palm kernel shells as aggregates. FUTY J. Environ. 2018; 12, 42-61.
KY Foong, UJ, Alengaram, MZ Jumaat and KH Mo. Enhancement of the mechanical properties of lightweight oil palm shell concrete using rice husk ash and manufactured sand. J. Zhejiang Univ. Sci A 2015. 16, 59-69.
VT Nguyen. 2011, Rice husk ash as mineral admixture for ultra-performance concrete. Ph. D. Dissertation. Delft University of Technology, Delft, Netherlands,
Indian Standard. Concrete mix proportioning - guidelines. Bureau of Indian Standard, New Delhi, India. 2019.
ASTM International. ASTM C143/C143M: Standard test method for slump of hydraulic-cement concrete. ASTM International, Pennsylvania, 2008.
MK Ismail and AAA Hassan. Influence of mixture composition and type of cementitious materials on enhancing the fresh properties and stability of self-consolidating rubberized concrete. J. Mater. Civ. Eng. 2016; 28, 04015075.
ASTM International. ASTM C109/C109M: Standard test method for compressive strength of hydraulic cement mortars. ASTM International, Pennsylvania, 2020.
JS Lim, CB Cheah and MB Ramli. The setting behavior, mechanical properties and drying shrinkage of ternary blended concrete containing granite quarry dust and processed steel slag aggregate. Construct Build. Mater. 2019; 215, 447-61.
ASTM International. ASTM C496/C496M: Standard test method for splitting tensile strength of cylindrical concrete specimens. ASTM International, Pennsylvania, 2017.
C Fapohunda, B Akinbile and A Shittu. Structure and properties of mortar and concrete with rice husk ash as partial replacement of ordinary Portland cement: A review. Int. J. Sustain. Built Environ. 2017; 6, 675-92.
MK Ismail and AA Hassan. Impact resistance and acoustic absorption capacity of self-consolidating rubberized concrete. ACI Mater. J. 2016; 113, 725-36.
British Standards Institution. BS 1881-122: Testing concrete - method for determination of water absorption. British Standards Institution, London, 2011.
