Characterization of Eucalyptus Lignin Fractionation from a MIBK-Based Solvothermal Process
DOI:
https://doi.org/10.48048/tis.2022.2894Keywords:
Eucalyptus, Biomass material, Lignin fractionation, Solvothermal process, OptimizationAbstract
In this study, the effects of sulfuric acid on cellulose yield, lignin removal, and lignin recovery in solvothermal fractionation of eucalyptus (EC) were studied. An acid concentration of 0.04 M sulfuric acid (H2SO4), temperature of 180 °C and residence time of 30 min resulted in maximum lignin removal from the solid phase, at 87.7 %. Lignin recovery in the organic phase under optimum conditions was 84.6 %. It should be noted that H2SO4 was the best catalyst in the optimal solvothermal process, and it increased the cellulose yield to 95.2 % in the solid phase. Additionally, the physicochemical and structural properties of the extracted lignin were analyzed using FTIR, TGA, elemental analysis, GPC, and Py-GCMS methods. Thermal degradation analysis showed that recovered lignin is primarily composed of syringyl, guaiacyl and p-hydroxyphenyl units cross-linked by C–C, inter-unit α-O-4, β-O-4 linkages. The weight average molecular weight (Mw) analysis of recovered lignin demonstrated a low molecular weight for recovered lignin (2.19 g/mol). However, the main phenolic derivatives in the extracted lignin obtained from EC were S-units (i.e., syringol, 4-methylsyringol, 4-vinylsyringol). In addition, G-units (4-vinylguaiacol, 4-methylguaiacol, phenol, 2-methylphenol, and 4-methylphenol) were obtained after release from H-units. Py-GCMS analysis showed the predominance of G-units (32.8 %) over S-units (57.4 %). This work demonstrated the potential of fractionated lignin in the production of valuable chemicals in biorefineries.
HIGHLIGHTS
- Eucalyptus was fractionated with solvothermal process with different conditions
- The maximum lignin removal of 87.7 % was achieved in the presence of catalyst of 0.04 M
- Organosolv fractionation enabled an extensive and selective delignification
- The structural changes of lignin were characterized comprehensively
GRAPHICAL ABSTRACT
Downloads
Metrics
References
R Ahorsu, F Medina and M Constantí. Significance and challenges of biomass as a suitable feedstock for bioenergy and biochemical production: A review. Energies 2018; 11, 3366.
A Kupczyk, J Mączyńska, G Redlarski, K Tucki, A Bączyk and D Rutkowski. Selected aspects of biofuels market and the electromobility development in Poland: Current trends and forecasting changes. Appl. Sci. 2019; 9, 254.
TB Rawal, M Zahran, B Dhital, O Akbilgic and L Petridis. The relation between lignin sequence and its 3D structure. Biochim. Biophys. Acta Gen. Subj. 2020; 1864, 129-547.
B Bujanovic, R Sally, R Richard, H Kolby and R Atalla. Polyoxometalates in oxidative delignification of chemical pulps: Effect on lignin. Materials 2010; 3, 1888-903.
RJA Gosselink. 2011, Lignin as a renewable aromatic resource for the chemical industry. Ph. D. Dissertation. Wageningen University, Wageningen, Netherlands.
T Klamrassamee, T Tana, N Laosiripojana, L Moghaddam, Z Zhang, J Rencoret, A Gutierrez, JCD Rio and WOS Doherty. Effects of an alkali-acid purification process on the characteristics of eucalyptus lignin fractionated from a MIBK-based organosolv process. RSC Adv. 2016; 6, 92638-47.
C Inkrod, V Champreda, M Raita and N Laosiripojana. Characteristics of lignin extracted from different lignocellulosic materials via organosolv fractionation. BioEnerg. Res. 2018; 11, 277-90.
A Sluiter, B Hames, R Ruiz, C Scarlata, J Sluiter, D Templeton and D Crocker. Determination of structural carbohydrates and lignin in biomass. National Renewable Energy Laboratory, Colorado, 2008.
P Chen, Q Zhang, R Shu, Y Xu, L Ma and T Wang. Catalytic depolymerization of the hydrolyzed lignin over mesoporous catalysts. Bioresour. Tech. 2017; 226, 125-31.
W Wanmolee, N Laosiripojana, P Daorattanachai, L Moghaddam, J Rencoret, JCD Río and WOS Doherty. catalytic conversion of organosolv lignins to phenolic monomers in different organic solvents and effect of operating conditions on yield with methyl isobutyl ketone. ACS Sustain. Chem. Eng. 2018; 6, 3010-8.
C Li, X Zhao, A Wang, GW Huber and T Zhang. Catalytic transformation of lignin for the production of chemicals and fuels. Chem. Rev. 2015; 115, 11559-624.
N Suriyachai, N Kraikul, W Techanan and N Laosiripojana. Fractionation of lignocellulosic biopolymers from sugarcane bagasse using formic acid-catalyzed organosolv process. 3 Biotech 2018; 8, 221.
TDM Florian, N Villani, M Aguedo, N Jacquet, HG Thomas, P Gerin and A Richel. Chemical composition analysis and structural features of banana rachis lignin extracted by two organosolv methods. Ind. Crops Prod. 2019; 132, 269-74.
SE Klein, J Rumpf, P Kusch, R Albach, M Rehahn, S Witzleben and M Schulze. Unmodified kraft lignin isolated at room temperature from aqueous solution for preparation of highly flexible transparent polyurethane coatings. RSC Adv. 2018; 8, 40765-77.
D Watkins, M Nuruddin, M Hosur, A Tcherbi-Narteh and S Jeelani. Extraction and characterization of lignin from different biomass resources. J. Mater. Res. Tech. 2015; 4, 26-32.
T Klamrassamee, T Tana, N Laosiripojana, L Moghaddam, Z Zhang, J Rencoret and WOS Doherty. Effects of an alkali-acid purification process on the characteristics of eucalyptus lignin fractionated from a MIBK-based organosolv process. RSC Adv. 2016; 6, 92638-47.
J Sameni, S Krigstin, DDS Rosa, A Lea and M Sain. Thermal characteristics of lignin residue from industrial processes. Bioresources 2014; 9, 725-37.
A Ház, M Jablonský, I Šurina, F Kačík, T Bubeníková and J Ďurkovič. Chemical composition and thermal behavior of kraft lignins. Forests 2019; 10, 483.
MB Vasile. Thermal degradation of lignin. Cellulose Chem. Tech. 2010; 44, 353-63.
B Lin, R Li, R Shu, C Wang, Z Cheng and Y Chen. Hydrogenolysis and hydrodeoxygenation of lignin in a two-step process to produce hydrocarbons and alkylphenols. J. Energ. Inst. 2019; 92, 784-91.
CL Waters, RR Janupala, RG Mallinson and LL Lobban. Staged thermal fractionation for segregation of lignin and cellulose pyrolysis products: An experimental study of residence time and temperature effects. J. Anal. Appl. Pyrol. 2017; 126, 380-9.
S Chu, AV Subrahmanyam and GW Huber. The pyrolysis chemistry of a β-O-4 type oligomeric lignin model compound. Green Chem. 2013; 15, 125-36.
J Ralph, K Lundquist, G Brunow, F Lu, H Kim, PF Schatz and W Boerjan. Lignins: Natural polymers from oxidative coupling of 4-hydroxyphenyl- propanoids. Phytochem. Rev. 2004; 3, 29-60.
